The adorne collection by Legrand offers solutions to match any taste and finishes to fit any personality. Whether you favor the clean lines of modern design, or cozy, cottage-style comfort, or even the classic elegance of a more traditional style, adorne is built to fit. Take your pick of white, magnesium, or graphite switches, dimmers, and outlets, and match them with a wide array of wall plate options. You will find everything from lush natural woods, metals, and fabrics to a brilliant spectrum of colorful solids. Watch these usually forgotten finishing touches transform your walls from blah to breathtaking, letting the personality of your design shine through.
I purchased these for a new construction. They ran wires only. No terminations. The package says easy. What can go wrong? Everything.
I started with the diagram on the package and on the connector. I followed the color code and tested the connection. It failed. I work with electronics and wiring. I'm not a rookie. So, I started all over again and it failed. I tried many combinations with no joy. I spent a few hours doing this. I wrote down the combos I tried. I could not figure it out. I finally had enough and quite the project for now.
I looked up the reviews and found some helpful information. Apparently there are 2 wiring diagrams on the connector and packaging. A and B. WHAT? So I picked up the project again. I used the B wire diagram. I got my connectors, tools, tester and diagram. I made the connections and tested the wires and Viola! It passed the test. Crazy. So, for us in the USA, we use diagram B. The orange and green are the difference.
I can now do my project. Thanks to the folks that wrote good reviews on this product.. Edro. Sun, 24 Sep 2023
