Compatible with Hand Wave Control & Triac Dimming
You can turn the light on/off and adjust the brightness without touching the cabinet light fixture, even when your hands are wet or dirty. Hand wave dimming works seamlessly with Triac dimming. You can hover your hand over the sensor for more than 2 seconds for smooth, stepless dimming or simply use Triac dimmers.
Multiple Connection and Installation Methods
To accommodate the current wiring and power setup in your home, we've developed two power connection methods for easy access and use. With the provided accessories, you can achieve seamless connections, perfect for straight, extended cabinet lighting. Additionally, you can connect multiple lights with jumper cables, allowing you to illuminate the corners of your cabinets without needing extra plugs.
Product Features
1. Each product operates with its own separate switch.
2. The color temperature can be adjusted to 3000K, 4000K, or 5000K using the CCT switch.
3. A quick horizontal swipe above the sensor (around 1 second) turns the device on or off.
4. A prolonged hand hover above the sensor (over 2 seconds) allows for continuous dimming, ranging from 10% to 100%. When the light is off, hovering your hand above the sensor will gradually increase the brightness to 100%. When the light is on, the first hover will decrease the brightness gradually, while the second hover will increase it.
5. The product features a memory function, such that if you set the brightness to 50% using the swipe switch, it will remain at 50% even after being turned off and back on.
6. Supports TRIAC dimming, with a brightness range from 10% to 100%.
7. TRIAC dimming and the hand swipe switch dimming functions are compatible. For example, if you set the brightness to 50% with the swipe switch, phase-cut dimming will start from that brightness level.
8. Two products connected in series cannot be synchronized for control.
9. The vertical sensing distance ranges between 3 to 8 cm, requiring the hand to be directly above the lamp sensor for activation.
10. It boasts a long lifespan of 30,000 hours, comes with a 3-year warranty, and is ETL listed, ensuring your rights and benefits are thoroughly protected.
NOTE
1. The maximum number of products that can be connected depends on the power cord's maximum load capacity. The included power cord supports up to 300W. To ensure a stable operating environment, it is recommended not to exceed 80% of the maximum load capacity (240W).
2. This LED under-cabinet light is not compatible with the TORCHSTAR Gun Safe Lighting Kit Extension Cable.
Specifications:
Wattage: 14W
Equivalent: 100W
Luminous flux: 960lm
Size: 22 Inch
Voltage: 120V AC
CCT: 3000K/4000K/5000K
Beam angle: 120°
Dimming range: 10%-100% (triac dimmers)
Waterproof rating: IP20
Lifespan: 30,000hrs
Working temperature: 14℉-104℉
Housing material: Die-casted aluminum
Finish color: White
