3.13 in. 8.7 W Dimmable LED Retrofit, White

At a Glance

IC Rated for Insulated Ceilings

Trim Size: 3.13 ''

Built-in LED Light

Dry, Damp or Wet Location Rated: Wet

About This Product

NICOR’s D-Series luminaries offer a comprehensive family of LED downlight fixtures that complement one another no matter your design space needs. The new 2” family packs a punch with its small, elegant design along with its high lumen output. Not only does this family work perfect for accent and task lighting, but the lighting output allows you to bring general ambient lighting into a space with a very small, architectural exposure. From LED color rendering and trim finishes to fixture performance, this series is a perfect choice for commercial, retail, institutional, and residential applications.

Features

Dimmable down to 10%
Uses standards household voltage
For IC-rated, airtight new construction application and use housing model 12200A-LED or 12201-LED-ICAT
For remodel applications and use housing model 12202R-LED-ICAT
Energy Star Compliant: Yes
Title 24 Compliant: Yes
Compatible Housing Part Number: 12200A-LED; 12201-LED-ICAT; 12202R-LED-ICAT
Voltage Type: Line voltage
Tools Needed for Installation: Normal
IMPORTANT - Requires a NICOR 2-inch LED Recessed Housing
Energy Star Rated, Uses less than 10 Watts
Dimmable to 10% with standard LED dimmers
Uses Standards Household Voltage (120 Volts)
For IC-Rated, Airtight, New Construction Housings, use NICOR Models 12200A-LED or 12201-LED-ICAT
For Remodel Housings, use NICOR Model 12202R-LED-ICAT
Lifetime Rated at over 35,000 hours
90+ CRI and R9 Over 50
Requires Nicor 2" recessed housing

Details

Product Type: LED Retrofit
Total Number of Pieces Included: 1
Construction Type: New Construction, Remodel
Insulation Type: IC Rated for Insulated Ceilings, Non-IC Rated (For Non-Insulated Ceilings Only)
Trim Shape: Circle
Trim Style: Decorative
Dry, Damp or Wet Location Rated: Wet
What is Dry, Damp or Wet Location Rated?: This indicates whether the fixture is safe to use in dry locations, damp locations (moist environments), or wet locations (direct exposure to water).
Material: Metal
Housing Required: Yes
Transformer Required: No
Maximum Wattage (Per Bulb): 8.6 Watt
What is Integrated LED?: This indicates that an LED light is built into the fixture. Integrated LED lights are more energy efficient and can last up to 50,000 hours. They cannot be replaced by the customer.
Number of Lights: 1
Voltage: 120 Volt
Imported: Yes
Wattage: 8.7 Watt
Bulb / Light Type: Integrated LED
Integrated LED Color Rendering Index (CRI): 93
Brightness (Lumens): 642lm
General Features: Airtight
Built-In Features: Dimmable
Location: Indoor / Outdoor
Compatible With: Sloped Ceiling
Color Temperature: 3,000K
