SPECIFICATION
Input Voltage: AC85-265V 50-60Hz
Light Source: 18pcs 15W RGBWA UV 6 IN 1 LEDs
Power Consumption: 270W
Colors: RGBW color mixing
Waterproof: IP 65
Beam Angle: 25 degree
Color Mixing system: 6IN1 RGBWA UV color mixing system
Control Mode: DMX512, Automatic, Strobe, Master & Slave
Operation Panel: LED Digital Display
DMX Channels: 7 / 9CH
Signal Input: 3-core XLR input
Signal Output: 3-core XLR output
Working environment: Temperature:-20℃- 40℃，humidity: 0%-90%
Housing Material : High temperature plastic & Alloy
Housing Color: Silver
Function: Color Changing, Color Fade, Strobe
Display: Digital display
DMX Channel Table
7 Channels:
Channel: Value (Function)
CH1: 0-255 (All dimming)
CH2: 0-255 (Red dimming)
CH3: 0-255 (Green dimming)
CH4: 0-255 (Blue dimming)
CH5: 0-255 (White dimming)
CH6: 0-255 (Amber dimming)
CH7: 0-255 (UV dimming)
9 Channels:
Channel: Value (Function)
CH1: 0-255 (All dimming)
CH2: 0-255 (Red dimming)
CH3: 0-255 (Green dimming)
CH4: 0-255 (Blue dimming)
CH5: 0-255 (White dimming)
CH6: 0-255 (Amber dimming)
CH7: 0-255 (UV dimming)
CH8: 0-255 (Strobe from slow to fast)
CH9: 0-127 (Choose color)
CH9: 128-169 (2-color jump)
CH9: 170-210 (Color jump from slow to fast)
CH9: 211-255 (Color gradient from slow to fast)
