CRB800 SERIES GRADE 1 HEAVY DUTY DEADBOLTS
Heavy Duty Single Cylinder Deadbolt. Deadbolt thrown or retracted by key from outside or by inside turn unit. Bolt automatically deadlocks when fully thrown.
FEATURES
TRIM - Wrought Brass or Stainless Steel.
DOOR RANGES - Adjustable 1 3/8" (40mm) to 2" (51mm) door thickness.
BACKSET - UL Listed 3 Hour Fire Rating 2 3/4" latch bolt. 2 3/8" optional.
DEADBOLT FACEPLATE - Standard 2 1/4" x 1 1/8" for 2 3/4" backset. Optional 2 1/4" x 1" for 2 3/8" backset.
STRIKE - 1 1/8" x 2 3/4" square corner. Extra security 1" throw bolt with 1/4" free spinning anti-cut through pin. 2 pcs x 3" screws with wood frame reinforcer greatly strengthens door frames.
BORE DIAMETER - 1" for latch, 2 1/8" for lock housing.
KEYWAYS - 6 pin solid brass C" keyway standard. Schlage E, Schlage C-K, Russwin D1-2-3-4, Corbin 59 / 60, Corbin-Russwin L4, Sargent LA-LB-LC, Falcon / Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept Medeco, Assa, Kaba and Cal-Royal (HSK) High Security Cylinders.
INTERCHANGEABLE CORE (IC) - Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST, FALCON and ARROW. Also available with SCHLAGE large format cylinders.
PACKAGING INCLUDES
Standard "C" 6-pin cylinder
Standard UL Listed 2 3/4" backset, optional 2 3/8" backset available. Please specify.
Latch: Backset latch size 1 1/8" x 2 1/4" faceplate.
Strike: 1 1/8" x 2 3/4" packet with 3" screws with wood frame reinforcer.
