Draper LCD Projector Lift

Draper's LCD Lift is compact, lightweight and accomodates most LCD/DLP projectors. Bomb bay doors open into the room, and the projector descends from the lift's traveling pan.

Features

• Dimensions: Model A: 17" x 24" x 24"
• Dimensions: Model B: 22-3/4" x 29" x 29"
• Plenum housing of aluminum, with doors finished in ceiling white.
• Contains two 110v power switched outlets.
• Contains current sensor that requires projector to cool before retracting.
• A flat ceiling closure, similar to that furnished for the Scissor Lift, is optionally available at no extra cost, simply put request into order notes before ordering.
• Can be used with our Aero Low Profile Lift Bracket to attach projector to lift.
• One year warranty against defects in materials and workmanship.

Dimensions & Data

LCD Lift A

• Overall Unit Size (HWL): 17¾" x 24" x 24"
• Projector Space (HWL): 11" x18" x18"
• Required Space Above Ceiling: 17¾"
• Clearance Below Ceiling: 12"
• Ceiling Opening: 24½" x 24½"
• Capacity: 65 lbs.
• Amperes: 1
• Downward Travel Distance: 11½"
• Travel Time: 16 sec.

LCD Lift B:

• Overall Unit Size (HWL): 22¾" x 29" x 29"
• Projector Space (HWL): 16" x 23" x 23"
• Required Space Above Ceiling: 22¾"
• Clearance Below Ceiling: 14½"
• Ceiling Opening: 29½" x 29½"
• Capacity: 65 lbs.
• Amperes: 1
• Downward Travel Distance: 16½"
• Travel Time: 21 sec.

Please Note:

• Subtract 47/8" from available projector height if Aero Low Profile Mount with Universal Projector Bracket is specified.
• Add 3/4" to height dimension if Ceiling Closure Panel is specified.
• Does not include any load placed on LCD Lift’s internal switched outlets.

Note: LCD Lift orders require a completed planning sheet. Please call for information.
